2 SPEAKERS = PAIR
General Specifications:
- Nominal Diameter: 6.5 inch
- Rated Lmpedance: 4Ohm
- Operating Bandwidth: 60 ~ 8KHz (-3dB)
- Power Handling Capacity: 50W RMS
- Sensitivity (1W/M): 88dB (±3dB)
- Voice Coil Diameter: 1 inch
- Resonance Frequency Fs: 40.0Hz
- DC Resistance Re: 3.4Ohm
- Mechanical Q Factor Qms: 3.66
- Electrical Q Factor Qes: 0.4796
- Total Q Factor Qts: 0.424
- Equivalent Cas air load Vas: 26.93 L
- Surface Area of Cone Sd: 0.0139 m2
- Efficiency Bandwidth Product EBP 83.4
- Voice Coil Over Hang X-max 3.5 mm
- Cutout: 5.60"
- Mounting Depth: 2.99"
- Basket: Pressed steel chassis
- Magnet Type: 16.6 oz.
- Cone Material: Polypropelyne
- Surround: Rubber
- Dust Cap: Polypropelyne
- Damper: Cloth
- Shipping weight: 6 lbs.
Thiele-Small Parameters:
Physical Information:
