4 1/2 digits LCD display with
42-segment bar graph AC/DC powered, complies with Protection class II,
overvoltage CATII of the IEC1010 (EN61010-1), Pollution degree 2 in accordance
with IEC-664.
Built-in storage compartment for accessories
True RMS
RS232C computer interface
Auto ranging
LCD backlit
Data hold
Relative measuring mode
Sleep function
Auto power-off and preserves the last value.
DCV:0-400m-4-40-400-1kV±0.3%
ACV:0-4-40±0.8%-400-750V±1.2%(40Hz-1kHz)
DCA:0-4m-40m-400m±0.8%-10A±2.0%(20A
for 30 Sec.)
ACA:0-4m-40m-400m±1.5%-10A±2.0%(20A
for 30 Sec.)
R:0-400-4k-40k-400k±0.5%-4M±1.0%-40Mohm±1.5%
CAP:0-4n-40n-400n-4u-20±2.0%-40uF±5.0%
Frequency:0-100-1k-10k-100k-1MHz±0.1%
Audible continuity:<50ohm
Diode Test:0.6mA,0.3V
