Specifications:
1) Model (output voltage & output current):
a) HY3002F-2 (2 x 0-30V, 2 x 0-2A)
2) Display type: 4 LED with 2 colors
3) Input voltage: 104 to 127V AC (60Hz), or 207 to 253V AC (50Hz)
4) Ripple and noise: CV 0.5mVrms
5) Protection: current restricted protection, short-circuit and reverse polarity
protection
6) Output type: dual output
7) The dual output can be connected in parallel or series, series voltage or parallel
current is the sum value of dual output
8) Dimensions: 365 x 265 x 164mm
MASTECH HY3002F-2 DUAL DC POWER SUPPLY (2 x 0-30V, 2 x 0-2A) DUAL COLOUR LED DISPLAYS
