- Output polarity : positive and negative
- Low ripple voltage less than 1mVp-p
- Overload protection circuit
- With bright Back Light
- State of art design
- Series and parallel operation available
Specifications:
Output Voltage : 0- 30V @ 0-10A
Output Current :0-10 A
Input Voltage: 110V/ 60Hz (Optional 220V/50Hz)
Constant Voltage/ Constant Current
Voltage and Current Variable
Power effect: CV<0.01%+1mV, CC<0.2% + 1mA
Overload effect: CV<0.01% +3mV, CC<0.2% +3mA
Waves and noises: CV<2mV r.m.s, CC <10mA, r.m.s
Protection: constant current and short-circuit protection
CV¡Ü0.1%+5mV(I>6A) CC¡Ü0.5%+20mA(I>6A) Load regulation :
CV¡Ü0.02%+10mV(I¡Ü6A) CC¡Ü0.5%+10mA(I¡Ü6A)
CV¡Ü0.1%+5mV(I>6A) CC¡Ü0.5%+20mA(I>6A)
Protection: High current limited.
Ripple & Noise: CV¡Ü3mVr.m.s CC¡Ü10mA r.m.s
Digital Voltage and current meters built in with Voltage resolution: 2.5% of display reading; 2.5% of Current resolution: display reading 2 years warranty Size: (mm) 362X 262X165, (inches) 141/4X101/4X61/2" Weight
